H2004
5MP Battery-Powered Camera System
- Resolution: 5MP
- Built-in battery with capacity - 2900mAh x 4
- Compatible with solar panel, forever powered
- MESH to meet long wireless distance
- Dual storage - SD card and hard drives
- Color Night Vision and Warm Light
- Sound and light alarm with red and blue light, Proactive Deterrent, Crime Prevention
- Free APP Available On, Playback in multiple view
H2004
5MP Battery-Powered Camera System
4K
Solar Power
Edge System
New
- Resolution: 5MP
- Built-in battery with capacity - 2900mAh x 4
- Compatible with solar panel, forever powered
- MESH to meet long wireless distance
- Dual storage - SD card and hard drives
- Color Night Vision and Warm Light
- Sound and light alarm with red and blue light, Proactive Deterrent, Crime Prevention
- Free APP Available On, Playback in multiple view
PAY WITH EASE
| Model NO. | H2 | |
| Video | Resolution | 3840*2160 （8MP） |
| Inputs | 8CH (WIFI 2.4G) | |
| Live | Resolution | 3840*2160 （8MP） |
| Frame rate | Max 3M@15fps+1M@15fps， (Auto fps, Auto bitrate) Max 1M@15fps (Auto fps, Auto bitrate) |
|
| Performance | ||
| Recording | Compression | Video : H.265/H.264 Audio: ACC/G.726/G.711a |
| Recording bandwidth | Max Up to 32Mbps ( main 3M * 8= 24M + sub 1M * 8= 8M) | |
| Frame rate | Dual Streaming recording | |
| Max 3M@15fps+1M@15fps， (Auto fps, Auto bitrate) Max 1M@15fps (Auto fps, Auto bitrate) |
||
| Event type | Human / Vehicle + PIR Detect | |
| MD + PIR(Sensitivity Level 0~100) | ||
| HDD (Full, Failure) | ||
| Search&Playback | Playback frame rate | - Single channel view Max 8MP@15fps (Auto FPS ) |
| - Multi channel view : 8CH Max 2MP@15fps (Auto fps, Auto bitrate) |
||
| Network | Transmission bandwidth | Max Up to 32Mbps |
| Max. remote users | 7 (Admin 1, User 6) | |
| Live stream | Main stream : H.265 Max 3MP@15fps+1MP@15fps, (Auto fps, Auto bitrate) Max 1MP@15fps (Auto fps, Auto bitrate) |
|
| Protocol support | TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTSP, NTP, HTTP, DHCP, SMTP, DNS, DDNS |
|
| UI | Local/VMS | Support |
| APP | IOS, Android | |
| P/W Reset | Support | |
| LED | - Power : GREEN - Record : RED - Network : BLUE |
|
| BEEP | Yes | |
| Dropbox | support (dropbox API 2.0) | |
| FW upgrade | - Network upgrade via webserver - Local USB Upgrade |
|
| Storage | Internal SD card Slot | Yes Max support 512GB |
| Internal HDD | HDD*1 (Ma x 16TB) (Not Included) | |
| USB (Back-up) | Yes | |
| File Format (Back-up) | LF, MP4 | |
| Interface | ||
| Video Output | HDMI | HDMI*1 (1280*1024, 1280*720, 1920*1080,2560*1440, 3840*2160) ※ EDID (monitor resolution auto detection) |
| Connections | Ethernet | 1 RJ45 10/100 Base-T |
| Wi-Fi | 2.4G / 5GHz | |
| USB | USB2.0 * 2 (for mouse and backup/upgrade) | |
| Application Support | USB Mouse | |
| General | ||
| OSD Language | English / DE / FR / ES / IT | |
| Mechanical design | Design | White / Plastic |
| Dimension (WxDxH) | 169.74 * 219.50mm * 63.67mm | |
| Weight (Without HDD) | 0.43KG | |
| Electrical | Input Voltage/Current | DC12V/2A |
| Power consumption | MAX 14W | |
| Environmental | Operating Temperature/Humidity | Temperature : 0°C~+40°C (32°F ~ 104°F) Humidity : 20% ~ 85%RH |
| Model NO. | W5A（5MP） |
| Lens | 2.8mm，F1.6 |
| Resolution | 5MP |
| Min. Illumination | 0Lux (IR LED ON) |
| WIFI Module | WIFI 2.4G |
| WIFI Transmission Distance | Max 500M(Empty No interference distance) |
| PIR Distance | 120°，23ft(7M) |
| Angular Field of View | H:111.7° V: 58.6° D: 134.1° |
| Shutter Mode | Auto |
| Gain Control | Auto |
| White Balance | Auto |
| Wide Dynamic Range | D-WDR |
| Digital Noise Reduction | 3DNR |
| Day & Night | CDS Detect, TRUE D/N, Auto |
| IR LED | 1PCS 2W IR LED |
| Warm White LED | 1PCS 2W Warm White LED |
| Warning Light | 2PCS Red+Green Light LED |
| AI Function | PIR+Person/Vehicle |
| Operating Temperature / Humidity |
-20°C ~ +50°C / Less than 90% RH ※ Startup : -10°C ~ +50°C |
| Ingress Protection | IP66 |
| Input Voltage | DC5V, TYPE-C Interface |
| Power Consumption | MAX 3.26W |
| Battery Capacity | 11600mAh |
| Mechanical design | White / Plastic |
| MIC | YES |
| SPEAKER | Internal 1Pcs 8Ω 1W |
| SD card slot | Max support 256GB |
