GLN-1532QP-EHL
32CH 4HDDs Network Video Recorder
- Maximum support for 32 channels of 4K IP camera input
- H.265 encoding and decoding
- Supports standard ONVIF protocol
- With 2 Gigabit Ethernet ports
- With 4 internal HDD drive bays,and 1 external eSATA port
- 16 alarm inputs and 1 alarm outputs
- Supports intelligent analytics such as facial recognition, human detection, vehicle detection, license plate recognition, perimeter intrusion, and line crossing statistics
- Allows remote access from mobile devices and computers
- Supports external alarm devices and features RCA interface for voice intercom
GLN-1532QP-EHL
32CH 4HDDs Network Video Recorder
4K
Solar Power
Edge System
New
PAY WITH EASE
| Model Name | GLN-1532QP-EHL | |
| Video | Resolution | 12MP,8MP,5MP, 3MP ,2MP(1080P),1.3MP(960P),1.0MP(720P) |
| Recording Bandwidth | Inputs | 640M |
| out | 640M | |
| Performance | ||
| Live/Playback | Compression | Audio: G.711A/G.711U Video : H.264/H.265/H.264+/H.265+ |
| Frame rate | 4K:240fps 4MP:480fps 2MP:960fps |
|
| Event | MD(Sensitivity Level 1~8) | |
| Videlo loss | ||
| Beep, Email, Push notification to Mobile APP |
||
| Playback function | Fast forward / backward (2x, 4x, 8x,16x) | |
| Slow forward (1/2x, 1/4x, 1/8x,1/16x) | ||
| Playback | Max 16CH playback | |
| Fisheye | Support | |
| UI/Monitoring | Local | UI5.0 |
| WEB | IE10/11 Safari V12.1 above Firefox V.52 above Google chrome V.57 above Edge V.79 above |
|
| Mobile viewer | Rxcamview | |
| AI | Face Detection | |
| Pedestrian Detection | ||
| Vehicle Detection | ||
| Cross Counting | ||
| Heat Map | ||
| Crowd Density Detection | ||
| Perimeter Intrusion Detection | ||
| Line Crossing Detection | ||
| Queue Legth Detection | ||
| License Plate Detection | ||
| Rare Sound Detection | ||
| Interface | ||
| P/W Reset | YES | |
| Monitors | HDMI | 2 （1024*768, 1280*720, 1280*1024, 1440*900, 1920*1080 , 2560*1440, 3840*2160/7680*4320/EDID）Async out *If the output resolution of HDMI 1 is set to 8K, HDMI 2 will be disabled |
| Ethernet | 2 RJ45 1000 Base-T | |
| USB | USB2.0*1(front) USB3.0*2(rear) |
|
| Audio out | 1 | |
| E-sata | 1 | |
| HDD | 4 SATA HDD, up to 12TB | |
| Line in | 1 | |
| RS485 | 1 | |
| Alarm Input/out | 16in /1out | |
| General | ||
| OSD Language | English/French/Spanish/Portuguese/German/Italian/Greek/Danish/Finnish/Hebrew/Turkish/Bulgarian/ Arabic/Korean/Japanese/Thai/Hindi/Romanian/Dutch/Polish |
|
| Mechanical design | Dimension (WxDxH) | 378*325.8*66mm |
| Electrical | Input Voltage/Current | 12V/5A |
| Power consumption (excluding hard disk) | 8W | |
| Environmental | Operating Temperature/Humidity | Temperature : -10°C~+50°C (14°F ~ 122°F) Humidity : Less than 90%RH |
