GL-485PVA-S1P6PX
20MP warm light 4-Directional Multisensor 360° Panoramic Dome Camera
  • 4 adjustable lenses in one camera cover up to a 360° field of view
  • 4-channel stream output, and each channel can output max. 5MP (2880 × 1620)
  • 4-channel starlight and 120dB WDR
  • All-In-One design, One IP, Multi-channel, multple use
  • The intelligent functions of 4 channels can be enabled at the same time
  • Built-in dual source illuminator（IR & warm light)
  • IP67/IK10 water resistant and vandal proof, preventing water ingress for outdoor use
GL-485PVA-S1P6PX
20MP warm light 4-Directional Multisensor 360° Panoramic Dome Cam
4K
Solar Power
Edge System
New
  • 4 adjustable lenses in one camera cover up to a 360° field of view
  • 4-channel stream output, and each channel can output max. 5MP (2880 × 1620)
  • 4-channel starlight and 120dB WDR
  • All-In-One design, One IP, Multi-channel, multple use
  • The intelligent functions of 4 channels can be enabled at the same time
  • Built-in dual source illuminator（IR & warm light)
  • IP67/IK10 water resistant and vandal proof, preventing water ingress for outdoor use
PAY WITH EASE
  • Visa
  • Mastercard
  • PayPal
Specifications Accessories Download Document
Model Name GL-485PVA-S1P6PX
Image Sensor 1/2.7″ Progressive Scan CMOS (EA)
Max. Resolution 2880x1620 (EA)
Min. Illumination Color: 0.006 Lux @ (F1.2, AGC ON), B/W: 0.002 Lux @ (F1.2, AGC ON);,0 Lux with IR on/White light on
Shutter Time 1/5s - 1/20,000 s
Day & Night IR Cut Filter
Angle Adjustment Four flexible lens in one track, slide range: -60° to 60°, tilt: 0° to 90°, rotate: 0° to 355°
Lens 2.8  ~ 12 mm，Varifocal motorized lens
Focal Length & FOV Horizontal field of view: 35.3° to 112.2°,Vertical field of view: 19.9° to 58.2°,Diagonal field of view: 40.5° to 137.2°
Lens Mount Φ16.7
Aperture Max. F1.3
Illuminator
Supplement Light Type IR and Warm light
Supplement Light Range Up to 30m(IR)/15m(Warm light);
IR Wavelength 850 nm
Smart Supplement Light Yes
Video
Main Stream 50 Hz: 25fps 5MP(2880x1620),4MP(2592x1520),3MP(2304x1296),1080P(1920x1080), 720P(1280x720)
60 Hz: 30fps 5MP(2880x1620),4MP(2592x1520),3MP(2304x1296),1080P(1920x1080), 720P(1280x720)
Sub-Stream 50 Hz: 25fps 1280x720,640x480,320x240
60 Hz: 30fps 1280x720,640x480,320x240
Moblie-Stream 50 Hz: 25fps 640x480,320x240
60 Hz: 30fps 640x480,320x240
Video Compression Main stream: H.265+/H.265/H.264+/H.264,
Sub stream: H.265+/H.265/H.264+/H.264/MJPEG,
Video Bit Rate 16 Kbps to 16 Mbps
H.264 Type Baseline Profile/Main Profile/High Profile
H.265 Type Main Profile
Region Of Interest (ROI) Yes
Audio　
Audio Compression G.711
Audio Bit Rate Auto
Audio Sampling Rate 8 kHz
Environment Noise Filtering Yes
Network
Protocols TCP/IP,HTTP,DHCP,DNS,DDNS,RTP/RTSP,
SMTP,NTP,UPnP,SNMP,HTTPS,FTP,PPPoE
Simultaneous Live View Up to 92 streams
API ONVIF( Profile S/G/T)
User/Host Up to 32 users, 2 levels: Administrator and User
Web Browser IE10/11
Safari  V12.1 above
Firefox V.52 above
Google chrome  V.57 above
Edge V.79 above
Image Settings Rotate mode, saturation, brightness, contrast, sharpness, and white balance are adjustable by client software or web browser
Day/Night Switch Day/Night/Image/Schedule
Wide Dynamic Range (WDR) 120 dB
Image Enhancement BLC, 3D DNR, HLC
Interface　
Ethernet Interface 1 RJ45 10 M/100 M/1000 M Ethernet port
On-Board Storage Built-in Micro SD/SDHC/SDXC slot, up to 256GB
Audio 1 input (RCA), 1 output (RCA)
Alarm 2 inputs, 2 outputs
Reset Yes
Event　
Basic Event Motion detection
Smart Event Face Recogniton, Pedestrian&Vehicle Detection, Line Crossing, Object Detection,
CrossCounting, Heat Map, Crowd Density, Queue Length, License Plate Recognition,
Intrusion, Region Entrance, Region Exiting
General
Power Max.39W
Input Voltage / Current ACV24/DCV12/Hi-POE
Material Alloy
Dimension Ø300 mm × 195 mm (11.8" x 7.7")
Package Dimension 500 mm × 395 mm × 385 mm (19.7" x 15.6" x 15.2")
Weight Camera：Approx. 4.6kg(10.1lb)
Operating Conditions -30～+55°C/less than ≤ 95% RH
Protection IP67, IK10, NEMA 4
